Low-priced cable protector halfround | Ranger cable protector halfround | 6 channels | 60 x 80 cm | cable protector for heavy traffic up to 7t | halfround cable protector | black | with reflectors | for events and construction sites

This Ranger cable protector is not only unbeatable in price! The inexpensive cable protector halfround offers robust overrun protection and reliable personal protection – making it the ideal accessory for events and construction sites. The internal cable channels (number: 6) are of different sizes and enable quick and tidy cable routing. Whether cars, forklifts, semi-trailers or other vehicles – the round floor channel made of robust PVC material can be driven over with loads of up to 7 tonnes on an area of 63 x 33 cm and is therefore also suitable for heavy-duty use. With a weight of just under 30 kg , the cable protector halfround is very stable on the floor and does not slip , so that many cable protectors can be laid one after the other over long distances.

Affordable cable protector halfround: design, material, properties and load capacity

The cable protector halfround is suitable for both pedestrian and heavy-duty traffic. It is made of granulated PVC material and can be driven over with loads of up to 7 t on an area of 63 x 33 cm. Ranger cable protectors reliably protect cables, hoses and lines from damage such as crushing or abrasion. The halfround cable protector also protects people from the risk of accidents. They prevent tripping and avoid the risk of accidental contact with live electrical cables.

The cable protector without cover consists of two parts: An internal narrow cable duct with 2 cable channels , each 5 cm wide, and the semi-circular overrun bridge (instead of a cover) itself, which has a further 4 channels 1.3 cm wide and 3 cm wide. The curved main element is 60 cm wide, 80 cm long and max. 8 cm high. Both elements are black.

The semi-circular shape of the inexpensive cable protector is particularly easy to cross on foot or in a wheelchair and can also be driven over comfortably by vehicles . The surface has a ribbed profile, which ensures slip resistance and sure footing in wet conditions, while reflectors provide safety in the dark. The solid PVC cable protector made from recycled granulate is resistant to oil, solvents, acids and petrol and protects cables and thin supply hoses securely against weather-related and mechanical damage. The cable protector can be used indoors and outdoors.

Ranger cable protectors halfround in detail:

Dimensions of the cable protector halfround

The two-part cable protector halfround has the following individual dimensions:

External dimensions of main element:

Available cable channels:

Cable protector halfround Assembly

The cable protector consists of a solid, halfround main element with an insertable floor channel. The cable protectors are modular in design, allowing any number of elements to be connected together, depending on the length of the exposed cables, wires and hoses.

Tip: The PVC cable protectors can be laid particularly stably if the inner elements are laid offset so that the main elements lying on top overlap each other in the middle.

Halfround cable protector - safety instructions

The black cable duct can be driven over with a load of up to 7 tonnes on an area of 63 x 33 cm . This value refers to the use of the cable protector on a level and solid surface and at walking speed. If you use the halfround cable protector on soft or sloping surfaces, the load capacity of the cable protector may be lower. In this case, please test the load capacity of the cable protector!

More affordable cable protectors and hose bridges from allbuyone

Our shop has a wide range of different cable protectors. We offer affordable cable protectors (Ranger) as well as very high-quality cable protectors. The various cable protector models differ mainly in the layout of the individual cable ducts, their appearance and their weight. The semi-circular cable duct is particularly well suited as an all-round cable protector for events and construction sites thanks to the different sizes of cable ducts. The semi-circular shape significantly reduces the risk of tripping . Our Ranger cable protector range also includes the Ranger cable protector (straight element) and angle elements. We also offer many other cable protectors for professional and long-term use on tours and for permanent installation in industry and commerce.

• Cable protector Ranger straight element
• Cable protector Ranger angle
• cable protector black line
• cable protector red line
• Defender cable protector © Midi
• Cable protector Yellow Jacket Classic
• Rubber hose bridge

Cable protector halfround - obtain approval

In general, you should always contact the relevant authorities before using a cable protector. If the cable protector is used as overrun protection on public roads, the relevant area must be marked with hazard warnings in accordance with official regulations. It may also be necessary to obtain additional official permits before using the black cable protector.

Note: Before using the cable protector, alwayscontact the relevant authorities (public order office, building authority, etc.) to clarify any necessary approvals and labelling requirements!

Cleaning and storing the cable protector halfround

As the cable protector halfround is manufactured without hinges or other moving parts, it is virtually maintenance-free. The cable duct can therefore be used without any problems even over long periods of time and on heavily soiled surfaces, e.g. on construction sites. To clean the floor duct, all you need is water and a mild cleaning agent. Store the semi-circular cable duct in a dry place and not upright!

Buy affordable cable protectors – large selection, best prices at allbuyone

You can order round cable protectors and other affordable cable protectors from the allbuyoneshop at from a wide range of products. We stock affordable cable protectors for construction sites and events, as well as professional cable protectors for long-term use. On request, your cable protector can be delivered within 24 hours. allbuyone – fast order processing, short delivery times. Further product information and personal advice are available on 089 - 122 89 06 22.
